Innovative Flooring Solutions

Citadel 4700

Electrostatic Discharge Control Coating

Electrostatic discharge causes a shocking $5 billion in lost profits annually. Protect yourself with Conductive and Static Dissipative floor toppings and coatings. Just walking across the floor can generate as much as 3,000 volts. It takes as little as 10 volts to cause damage to sensitive equipment and products, even ignition of flammable solvents and chemicals. 4700 ESD Control systems provide more effective protection against static and sparking than tile, carpet, and mats:

  • Conductive: for areas requiring low resistance (25,000 ohms to 1 megohm @ 500 V based on NFPA 99 test method)
  • Static dissipative: for areas where electrostatic charge build-up hinders productivity (1 megohm to 1,000 megohms @ 100 V based on ASTM F test method)
  • Seamless surface stays in place, is non-porous, and easy to clean without dusting or waxing
  • Two resistance ranges protect against a variety of acids, alkalis and solvents, in addition to physical impact and water absorption

Light to medium service areas in a range of industries, where foot and rubber-wheeled traffic are typical, can benefit from the static dissipative abilities of 4700 SD S coatings.

4700-C SL (Self-Leveling Conductive Coating)

Components 100% Solids Epoxy

Turnaround Time 8-12 hours (foot); 72 hours (full); 4 days (chemical)

Primer Penetrating Prime & Seal Primer and Primer ESD

Sealer None

Texture Smooth

Application Type Type II

Film Thickness 90-105 mils

Gloss & Color Retention Better

Installation Temperature 70°–90°F (21°–32°C)

Chemical Resistance Mild to Moderate

Abrasion Resistance Rubber Wheel

Impact Resistance Mild to Moderate

Thermal Shock Resistance Mild

Key Industries/Typical Applications
Self-leveling conductive coating for potentially explosive areas in industrial manufacturing, institutional and electronics like pyrotechnics processing areas, powdered production plants and airbag plants.

4700-SD SL (Self-Leveling Static Dissipative Coating)

Application Type Type II

Film Thickness 90-105 mils

Gloss & Color Retention Better

Installation Temperature 70°–90°F (21°–32°C)

Chemical Resistance Mild to Moderate

Abrasion Resistance Rubber Wheel

Impact Resistance Mild to Moderate

Thermal Shock Resistance Mild

Key Industries/Typical Applications
Self-leveling static dissipative coating for industrial manufacturing, institutional and electronics like clean rooms, hospitals, automated assembly areas, computer control rooms, semi-conductor and relay assembly areas, printing press areas and electronic manufacturing plants.

4700-SD S (Static Dissipative Coating)

Application Type Type II

Film Thickness 16 mils

Gloss & Color Retention Good

Installation Temperature 70°–90°F (21°–32°C)

Chemical Resistance Mild to Moderate

Abrasion Resistance Rubber Wheel

Impact Resistance Mild

Thermal Shock Resistance Mild

Key Industries/Typical Applications
Static dissipative floor coating for industrial manufacturing, institutional and electronics like clean rooms, hospitals, automated assembly areas, computer control rooms, semi-conductor and relay assembly areas, printing press areas and electronic manufacturing plants.

4700 System SC Colors
